Product Description

* Instruction:

The Cosmetic Blender Vacuum Emulsifying Lower Homogenizer Eumlsifier is consisted of water pot , oil pot , emulsifying pot , vacuum system , electric control system , heating system , mixer system , operation platform .

The machine is applied to luxury skincare product , like facial cream , hand cream , daily chemical care products , biopharmaceutical , food , paint , ink , nanometer materials , petrochemical , printing and dyeing auxiliary , pulp and paper , pesticide , fertilizer , plastic and rubber , electrics and electronics , prominent for materials of high base viscosity and high solid content .

*Characteristic:
The Cosmetic Blender Vacuum Emulsifying Lower Homogenizer Eumlsifier , vacuum homogeniser is professionally designed according to the ointment manufacturing process of cosmetics and ointments etc products through introducing advanced technology from abroad. The machine unit is composed of pre-treating boiler, vacuum emulsifying and blending boiler, vacuum pump , hydraulic system, dumping system, electric control system and work platform etc.The machine unit is featured by simple operation, stable performance, good homogenizing performance, high production efficiency , convenient cleaning, reasonable structure, small land area and high automatic degree.

*Technology Parameters:

Technical Parameter
Capacity	Homogeneous motor		Stir motor		Dimensions (mm)			Total power	Limit vacuum
Capacity	KW	r/min	KW	r/min	Length	Width	Height	KW	Mpa
5L	0.37	1450/2800	0.18	0-83	1260	540	1600	5	-0.09
10L	0.75	1450/2800	0.37	0-83	1300	580	1600	6	-0.09
50L	3-5.5	1450/2800	1.1	0-83	2600	2250	1900	9	-0.09
100L	4-7.5	1450/2800	1.5	0-83	2600	2500	2400	32	-0.09
200L	5.5-11	1450/2800	2.2	0-83	2950	3000	2700	10	-0.09
300L	7.5-11	1450/2800	2.2	0-83	3100	3000	2800	13	-0.09
500L	11	1450/2800	4	0-83	3600	3550	3200	17	-0.09
1000L	15	1450/2800	5.5	0-83	4000	3850	3600	25	-0.09
2000L	15	1450/2800	7.5	0-83	4500	4400	3800	32	-0.09

*Usage:
It is suitable for production of ointment and cream products in cosmetic and pharmaceutical plants. The emulsifying effect is more prominent for materials of high base viscosity and high solid content.

*Advantages:

1> Strictly according to GMP standard design and production , polish meet 300U

2> The inner parts adopts 316 stainless steel
3> Bearing adopts Japanese NSK

4>Imported frequency conversion control
5>Machinery sealing with excellent sealing quality and performance , the homogenizer can work 24 hours continuously
6>Scraper blending and stable blending work at the same time

*MOQ: 1 set

* Packing:
1> Outer packing: plywood case
2> Inner packing: PE film wrapping overall

*Shipping:
FOB port: Guangzhou or Shenzhen
* After-sales service:
1> one year from date of delivery, if any spare parts be broken within warranty and not caused by improperly operation, we would offer the new parts for free.
2> Provide professional after-sales service engineers to abroad installation and debugging.

*About us:
We are a professional manufacturer of cosmetic,chemical& pharmaceutical machinery and equipment more than 17 years .Product lines range from:
1> Cosmetic Machinery: water treatment ,vacuum emulsifying machine,liquid detergent mixing machine,storage tank,solid soap making machine,perfume making machine, filling machine etc.
2> Chemical Machinery: reactor, mixing equipment,separation equipment, storage tank etc.
3> Pharmaceutical Machinery: vacuum ointment machine,sanitary stainless reaction pot,alcohol deposition can, collocation tank etc.

*Why Choose Jinzong Machiney?

1. More than 17 years in Cosmetic and cheimical industry
2. Quality, 80% materials and components are purchased from 3M, ABB, Siemens, Panasonic, Schneider
3. Good reputation in industry.
4.Have a Professional after-sales service engineering team
5.Large scale and strong strength
